ZHA_Sheikh Zayed Bridge_-®Hufton+Crow_15.jpg
sheikh zayed bridge - the 3rd crossing, abu dhabi, office of zaha hadid. 1999-2010.
3D-CAD model steel arch-beam design by archirodon-site based contractor engineer ramzi ilyad
steel plate beam manufacture, jebel ali, dubai.
main channel span steel arches. concrete cantilever road-deck beams + marina piers
bridge lighting
plan study of patterns of lighting in arches above and beneath road deck, projected into the water
dover
dover - 3D from contour plan study.jpg
imagined view of from durham hill
dover castle + dock silhouetted on the horizon with new dover laid out in front
3rd ranked entry for nairobi 2030 metropolitan masterplan competition, austin-smith:lord, 2008
nairobi 2030
nairobi
